China Pipe Packaging Machine Factory
Turn your finished pipes into consistent, shipment-ready bundles with less manual handling.
We build your pipe packaging system around your pipe diameter, length, pipes per bundle, packaging method and required production rate. From counting and bundle forming to strapping, bagging and final outfeed, every station is sized to the pipe you actually run.
Four numbers are enough to start. Send these and you get a configuration, not a generic catalog.
- Input 01 Pipe OD
- Input 02 Pipe Length
- Input 03 Pipes Per Bundle
- Input 04 Packaging Method
Get To The Right Packaging Setup Faster
Jump to whatever matters first, whether you are sizing bundles per hour, choosing between strapping and bagging, or getting your pipe specs in front of us for a quote.
Package Requirements
Pipe OD, length, pipes per bundle
Packing Configurations
Strapping, bagging, film, pallet
Counting & Bundle Formation
Accurate counts, tight bundles
Pipe & Package Protection
No scratches, no loose ends
Packing Capacity
Bundles per hour vs line speed
Online vs Offline
Inline with extrusion or standalone
Changeover & Operation
New pipe size in minutes, not hours
Packaging Problems
Miscounts, loose straps, jams
Factory Manufacturing
What we build in house
Inspection & Acceptance
Run tested with your pipe before shipment
FAQ
Voltage, lead time, warranty
Packing Line RFQ
Send bundle specs, quote in 24 hours
Define The Bundle Before The Machine
Pipe diameter alone does not size a packing line. The counting, forming and packing stations are matched to the bundle that leaves your line, so the first thing we need is a clear picture of that bundle.
Four groups of numbers cover it. Send what you have, even if some are still estimates.
Pipe Size + Pipe Length
What enters the line
Bundle Count + Bundle Size
What leaves the line
Packaging Method
Strap, film or bag
Production Rate
Pipes or bundles per hour
Packing Line Configuration
Stations matched to your bundle
Send What You Have, We Fill In The Rest
Photos of the bundles you ship today, your pipe sizes and the pipes per bundle are enough to start. We come back with the numbers still missing and what each one changes in the line, so nothing gets sized on a guess.
Choose The Packing Configuration You Need
You do not have to automate every packaging step at once. Start with the operation that still takes the most hands on your floor, then add the next station when the bundle or the volume asks for it.
Four configurations cover most pipe lines. Each one can be added to what you already run.
Swipe to compare the four configurations
| Configuration | What It Automates | Suitable For | Integration |
|---|---|---|---|
|
Option 1
Pipe Counting & Bundling |
What It Automates Pipe accumulation, counting, alignment and bundle forming. | Suitable For Lines where operators still count pipes by hand and lay up each bundle before strapping. | Integration Runs after your existing stacker, or with its own pipe infeed. |
|
Option 2
Bundling & Strapping |
What It Automates Bundle forming, holding and automatic strapping. | Suitable For Bundles that need to be held tight and secured before they move to storage or the truck. | Integration Fits into an existing bundling or conveying section. |
|
Option 3
Bundle Bagging / Wrapping |
What It Automates Film wrapping, sleeve feeding or bagging, matched to the package you ship. | Suitable For Bundles that need surface, dust or transport protection on top of the strap. | Integration Follows your existing bundling and strapping section. |
|
Option 4
Fully Automatic Packing Line |
What It Automates Counting, alignment, bundle forming, strapping, bagging or wrapping, and outfeed in one line. | Suitable For Plants that want to take manual handling out of the whole packing process, not one step. | Integration Online, connected to the extrusion line, or offline as a standalone packing cell. |
Not sure which option fits? Tell us which packing steps are still manual today and the bundle you need. We map them to one of the four and quote that, not the whole catalog.
Count Every Pipe, Form The Same Bundle Every Time
Before a strap or a bag goes on, the right number of pipes has to be separated, counted, lined up and held as one stable bundle. A miscount here becomes a short bundle at your customer, and a loose bundle here becomes a jam at the strapper.
Five stations do this work. Each one is set around your pipe size, pipes per bundle and the bundle dimensions you ship.
Controlled Pipe Feeding
Pipes arrive from your stacker, buffer table or infeed and enter the counter one after another, not in a heap. When two pipes ride on top of each other at the infeed, the count downstream is already wrong, so the feeding pace is the first thing we set.
Set by: What feeds the line today, stacker, buffer or by hand
Accurate Pipes Per Bundle
The counting station separates the pipes and releases exactly the number you set before anything moves to forming. The target count comes straight from your packing spec, and it can be changed from the panel when you switch to a different bundle.
Set by: Pipes per bundle for each pipe size you run
Aligned Pipe Ends
Before the bundle is secured, every pipe end is pushed to the same line. A flush end makes a bundle that looks right on the truck, and it keeps the strap and the bag from catching on a pipe that sticks out.
Set by: Pipe length and whether one end is belled
Defined Bundle Arrangement
The counted pipes are laid into the shape your bundle needs, hexagonal, square or a fixed row count. The former is built around the finished bundle size, not the pipe diameter alone, so the same machine can hold a different arrangement for each pipe size.
Set by: Bundle dimensions or the arrangement your customer specifies
Stable Bundle Formation
Once the pipes are counted and arranged, the bundle is closed and held under pressure while it moves to the next station. Nothing shifts between forming and strapping, so the strap goes onto a tight bundle instead of pulling a loose one together.
Set by: Bundle weight and the next step, strap, wrap or bag
One Line, A Count And A Bundle Shape For Every Size
A 32 mm pipe and a 110 mm pipe do not share a bundle count or an arrangement. Each size gets its own recipe on the panel, so your operator picks the size and the counter, aligner and former follow. To build that, we need every size you run on the line, not just the one you run most, so the former is sized for your largest bundle and still holds your smallest pipe.
- Count stored per pipe size
- Arrangement stored per pipe size
- Changed from the panel, no retooling
Secure The Bundle Without Marking The Pipe
A bundle has to stay tight through the forklift, the truck and the yard, but every point that holds it also touches the pipe. Too much strap tension leaves a ring in the wall, a hard guide leaves a scratch, a drop between stations leaves a dent.
The packing line is set for both at once: the package your customer expects to receive, and a pipe surface that still looks extruded when it arrives.
Strapping Pressure Under Control
Enough tension to hold the bundle, not enough to press a ring into the wall. The setting comes from your pipe size, wall stiffness, bundle weight and the strap you use.
Depends on: Pipe stiffness, bundle weight, strap type
Fewer Hard Contact Points
Guides, supports and pushers that touch the pipe are chosen and placed so the pipe slides instead of scrapes. Rubbing on a moving bundle shows up later as a dull stripe on a glossy pipe.
Depends on: Pipe material, surface finish, bundle path
Stable Transfer Between Stations
A formed bundle can still get hurt on the way. Transfers from former to strapper to bagger are matched in height and speed so the bundle keeps its shape and the outer pipes keep their surface.
Depends on: Bundle weight, station spacing, line rate
Clearance For Socket Ends
Belled ends stick out past the body of the bundle. Alignment, arrangement and contact points are set so the sockets do not knock into each other or take the strap load on their own.
Depends on: Socket OD, socket length, belled end position
If you already had pipes rejected for strap marks, scratches or cracked sockets, send a photo of the damage with your pipe spec. It tells us which station caused it and what to change.
Strap, Film, Bag, Or All Of Them In Sequence
Each option adds a station to the line. Pick the package your customer expects to receive and we build the stations behind it.
Strap
Holds the formed bundle in shape through handling, storage and truck loading. The baseline for every pipe bundle, and often all a domestic customer asks for.
Adds to the line: strapping station
Film / Sleeve
An outer skin against dust, dirt and surface marks. Worth it where bundles sit in the yard for weeks, travel far or pass through several hands before they reach the site.
Adds to the line: wrapping or sleeve station after strapping
Plastic Bag
A closed package when your packing spec asks for the whole bundle to be covered, ends included. Common for smaller diameters and for customers who store pipe indoors.
Adds to the line: bagging station, bag feed sized to your bundle
Woven Bag
A heavier outer bag for export loads, container stuffing and customers whose packing standard names the bag. Takes more abuse than film and keeps the bundle clean to the last mile.
Adds to the line: bagging station with woven bag feed
Not sure which one your market expects? A photo of a bundle you already ship, or one your competitor ships, is enough for us to name the package and the stations.
Match Packing Capacity To Your Line Output
The packing line has to finish bundles as fast as the extruder makes pipe, with margin. Size it on your real pipe output and the bundle you ship, not on the top speed printed on one strapping head.
Three numbers set the capacity. Put yours into the example on the right and see the cycle the line has to hold.
The Complete Bundle Cycle
Count, align, form, strap, bag, discharge. The slowest of these sets your real capacity.
Pipes Per Hour
What your extruder and cutter actually deliver, or the target for the new line.
Pipes Per Bundle
The count in each finished bundle, from your packing spec.
Bundles Per Hour
What falls out of the first two. This is the number the whole line has to keep.
Bundles Per Hour
30
Finished Bundle Cycle
1 every 2 min
Check capacity by the complete bundle cycle, not by the maximum speed of one packing station. A strapper rated for 60 bundles an hour helps nothing if counting and forming only release 25.
Choose Online Or Offline Packing
The layout depends on how pipes reach your packing area, how many extrusion lines the packer has to serve, and whether production and packaging run at the same rate.
Neither is the better machine. One fits a dedicated line, the other fits a shared packing hall.
| Criteria | Online Packing | Offline Packing |
|---|---|---|
| Workflow | Cutting / Stacking Packing Outfeed | Production Temporary Storage Packing |
| Best For | One dedicated extrusion line with a stable pipe and bundle spec that rarely changes. | Several extrusion lines feeding one packer, or packing specs that change from order to order. |
| Main Advantage | Pipe goes from cutter to bundle without a forklift in between. Less transfer, fewer hands, fewer marks. | You schedule packing when it suits you and share one packer across lines that run different sizes. |
| Capacity Planning | The packing cycle has to match the extruder output all shift long. Size it to the line, with margin. | Packing runs at its own pace from a buffer, so extrusion speed and packing speed do not have to agree. |
| Factory Layout | Needs floor length behind the stacker and a direct connection to the line. | Goes in a separate packing area, anywhere a forklift or conveyor can bring the pipe. |
Pick The Layout Your Floor Already Decided
Choose Online Packing When
- One extrusion line feeds the packer and the pipe spec holds for long runs.
- You have floor length behind the stacker for a direct connection.
- The goal is to take the forklift out between cutting and bundling.
Consider Offline Packing When
- Several lines share one packing system.
- Packing specs change often, by customer or by order.
- Your layout leaves no room for a direct connection to the line.
Know What Changes Between Pipe Sizes
When one packing line handles more than one pipe diameter, bundle count or package format, changeover time depends on how many things your operator has to touch. Three groups cover all of them.
Settings live on the panel as recipes. Mechanical positions and packaging materials are what still take hands, so those are what we design to be quick.
Control Settings
Pick the next spec on the panel and the pipe count, bundle quantity and cycle settings load with it. No re-typing numbers at the start of every run.
Changes With The Spec
- Pipes per bundle and bundle count
- Strap count and strap positions
- Cycle timing for the new bundle rate
Mechanical Adjustments
Guides, stops and forming positions move to suit the new diameter, length or bundle size. Scales and locking handles on these positions are what turn an hour into minutes.
Changes With The Pipe
- Infeed guides and counting gate
- End stops for the new pipe length
- Bundle former width and height
Packaging Materials
A bigger bundle needs a wider sleeve and a longer bag. Check the material against the new finished bundle before the first one reaches the bagger, not after.
Changes With The Bundle
- Strap position on the bundle
- Film or sleeve width
- Bag size and bag type
Tell us the two or three sizes you switch between most. We tell you which of these three groups each switch touches, and where a quick-adjust option pays for itself.
First Bundle Check
Count, ends, dimensions and package, before the line goes back to continuous.
Four Checks Between The Last Size And The Next
-
1
Load The New Packing Requirement
SettingsConfirm pipe size, pipes per bundle and the packaging method on the panel. If the recipe exists, this is one selection.
-
2
Adjust Size Dependent Positions
MechanicalSet the guides, stops and bundle forming sections to the new pipe and bundle. Scales on each position mean setting a number, not measuring.
-
3
Check The Packaging Material
MaterialsConfirm the strap, film, sleeve or bag on the machine matches the new bundle before the first one reaches that station.
-
4
Verify The First Finished Bundle
CheckCount the pipes, look at the ends, measure the bundle and inspect the package. Then release the line to continuous production.
A good changeover procedure makes it obvious what is a setting, what is a mechanical adjustment and what is a material change. That is what we hand over with the line.
Where Pipe Packaging Usually Goes Wrong
Whether you are replacing hand packing or upgrading a line you already run, the finished bundle is where problems show up. The cause is almost always one station earlier.
Pick the symptom you see. The panel shows which station it usually starts at and what to check first.
Wrong Number Of Pipes Per Bundle
One pipe too many or too few, now and then, almost never comes from the counter itself. It comes from pipes arriving on top of each other or too close together, so the sensor sees one where there were two. Small diameters do this most.
Check First
Pipe Ends Do Not Line Up
Uneven ends make the bundle look careless, and a pipe that sticks out catches the strap or tears the bag. The stop position has to match your pipe length, and the pipes have to be held after alignment, not left free to slide back before the bundle moves on.
Check First
Bundles Loosen After Forming
A tight strap on a loose bundle is still a loose bundle. If the pipes shift between forming and strapping, the strap closes on air. The arrangement, forming position and holding pressure have to keep the bundle in shape until the last strap is on.
Check First
Pipes Are Scratched Or Marked
If surface matters to your customer, the bag is not where to look. Guides, supports, transfer points and strap tension each leave their own kind of mark. A photo of the mark usually tells us which station made it.
Check First
Bagging Or Wrapping Is Unstable
Film and bags want the same bundle every time. If bundle size or alignment changes from pack to pack, feeding, covering and sealing all drift with it. The fix is usually upstream, in forming, not in the bagger.
Check First
Packing Falls Behind Production
Pipes piling up after the stacker means the packing cycle is slower than the extruder. Pipes per hour, pipes per bundle and the number of packing steps have to be checked together, as one cycle, before the line is sized.
Check First
Pick The Symptom You See
Seeing more than one of these? Send a photo of the bundle and your pipe spec. We trace it back to the station.
WhatsApp MaggieSee How Your Pipe Packing Line Is Built
Frame fabrication, conveyor assembly, counting, alignment, bundle forming, strapping, bagging and control integration all happen under one roof, and the complete line is assembled and run here before it is prepared for shipment. You can look at the actual build, the key mechanisms and the full line running, with your pipe, before anything is crated.
Zhangjiagang City, Jiangsu, China
Watch Your Own Line Run, Not A Showroom Video
Send a few of your pipes and we run them through the finished line on a live video call, from infeed to the bagged bundle on the outfeed. If you would rather see it in person, the factory is in Zhangjiagang, about two hours from Shanghai, and Maggie arranges the visit.
- Live video of the build at each stage
- Full line test with your pipe on camera
- Factory visit arranged on request
Test The Finished Bundle, Not Just The Machine
Before shipment, the complete packing process runs against the pipe, bundle, package and rate you confirmed. A machine that cycles is not the pass mark. Repeated bundles that all come out right is.
Five checks, all recorded in the acceptance report with photos and video, so you see what we saw.
Pipe Handling
Feeding, separation, alignment and transfer through the whole line, watched for impact, rubbing and any mark on the pipe. Your pipe, not a test bar.
In the report: Video of the pipe path, surface photos before and after
Counting Accuracy
A run of bundles, not one, each opened and counted against your pipes per bundle. The point is to prove the feed and count stay right in continuous operation, not just on the first cycle.
In the report: Bundle by bundle count sheet
Bundle Quality
End alignment, bundle dimensions, compactness and whether the bundle stays stable when it is lifted and moved, the way it will be in your yard.
In the report: Measured dimensions, end alignment photos
Packaging Quality
Strap position and tension, and the film, sleeve or bag where you have one. The package has to match the packing spec you confirmed and leave no mark on the pipe underneath.
In the report: Strap layout, package condition photos
Cycle And Line Integration
Repeated automatic cycles at your required rate, with buffer operation, upstream signals and finished bundle outfeed all running together the way they will behind your extruder.
In the report: Measured bundles per hour, full cycle video
Sign Off On Repeated Bundles, Not One Good Cycle
Acceptance is measured against what you agreed, not against a demonstration. Watch the line produce bundle after bundle at the confirmed rate, open a few, and compare them with the spec. One clean cycle proves the machine moves. A run of identical bundles proves it is ready for your floor.
Measured Against
- Pipe Specification
- Pipes Per Bundle
- Bundle Dimensions
- Packaging Method
- Production Rate
What You Compare
Bundle one, bundle ten, bundle thirty. Same count, same ends, same size, same package.
Questions Buyers Ask Before Ordering A Packing Line
Ten questions that come up in almost every packing line inquiry. If yours is not here, send it to Maggie and you get a direct answer, not a brochure.
1 What information do you need to configure a pipe packing line?
Your pipe OD range, pipe length, pipes per bundle, bundle size or shape, production rate, packaging method, and whether the line runs online behind the extruder or offline. If you already ship a bundle, a photo of it or your packing spec saves a round of questions.
2 Can one packing line handle different pipe diameters and bundle sizes?
Yes, within a defined range of pipe sizes and bundle specs. Each switch can mean a recipe change on the panel, guide and stop adjustments, a different bundle forming position and different packaging material. Confirm your whole product range before the line is configured so the range is built in, not bolted on later.
3 Can the machine automatically count the pipes in each bundle?
Yes, counting sits before bundle forming. What makes it reliable is not the sensor alone but stable separation and controlled feeding, so each pipe passes the sensor on its own and the exact quantity is released every time.
4 How do you keep the pipe ends aligned and the bundle stable?
The pipes are pushed to a common end line before final forming, and the formed bundle is held under pressure until the strap or bag is on. Alignment, forming and holding positions are set to your pipe length, bundle count and the finished bundle dimensions.
5 Can the packing line connect with my existing pipe stacker?
In most projects, yes. We check the stacker discharge height, pipe transfer direction, buffer space, production rate, control signals and your layout first. If the way your stacker hands off pipe is compatible with the new packing section, it stays in the line.
6 Should I use an online or offline packing line?
Online when one production line feeds the packer continuously and the packing cycle can keep up with it. Offline when several extrusion lines share one packing system, packaging specs change often, or your layout has no room for a direct connection.
7 Do I need a complete automatic packing line?
Not necessarily. If counting, stacking or another step already works for you, automate only the steps that are still manual. The configuration can be counting and bundling, strapping, bagging, or the whole process, depending on what your line already does well.
8 How do you select between strapping, film, sleeve and bag packaging?
By how the bundle is handled, stored and shipped, and by the appearance and protection your customer expects. If your market already asks for a specific strap, film, sleeve or bag format, the packing section is built around that spec. We do not change your package to suit the machine.
9 How do you prevent scratches or deformation during packing?
Pipe protection is designed into every step, feeding, alignment, forming, transfer and strapping, not added at the bag. Contact surfaces, bundle movement and strap pressure are controlled to limit rubbing, impact and concentrated load. Socketed pipes get extra clearance at the ends.
10 How do you confirm the packing line can meet our production rate?
We work out the bundle rate from your pipes per hour and pipes per bundle, then check that counting, alignment, forming, strapping, bagging and outfeed all fit inside that cycle. Before acceptance, the line runs repeated automatic cycles so you see finished bundle quality and continuous rate, not a single demonstration.
Still have a question about your pipe, your bundle or your layout? Ask it the way you would ask on the factory floor. Maggie answers in person.
Send Your Pipe And Bundle Details To Maggie
Pipe OD range, length, pipes per bundle, the package you ship and your pipes per hour. A few lines is enough to get a real packing line configuration back, not a price list.
Maggie
Sales, QTech Machinery
Replies within 24 hoursYour message reaches me directly. If only one packing step is worth automating right now, or your bundle count problem is really a feeding problem, I will tell you that before you spend anything.
What Comes Back To You
- Packing configuration matched to your pipe OD, length, pipes per bundle and package
- Bundle cycle checked against your pipes per hour, with margin
- Online or offline layout and stacker connection matched to your floor
- Repeated bundles run with your pipe before the line is packed
Maggie
Sales, Zhangjiagang Qinxiang Machinery Co., Ltd.
Get Your Packing Line Configuration
Four fields. Fields marked are required, and nothing else is asked of you.
